Configure HTTPS Proxy on IOS

Many proxy utility apps say that they support HTTPS proxy on IOS, but not true. So far, Only two apps can configure HTTPS proxy truly with WiFi and cellular data.

Apps

Both of them are support “MITM“, which can decrypte SSL traffic. Is it the reason?

Shadowrocket

Surge

Tutorial

Get SSL Certificate

There are two method to get the certificate, which can install on IOS.
1. Setup HTTPS proxy on Foxyproxy, an extension of Firefox, and add the certificate by the notice from Foxyproxy.
   Options–>Advanced–>Certificates–>View Certificates–>Servers–>HTTPS Proxy Certificate–>Export

2. If you deploy the HTTPS proxy server with openssl, export the certificate with “der” format.

   1 2 3

   openssl genrsa -out cakey.pem 2048 openssl req -new -x509 -key cakey.pem -out cacert.pem -days 3655 openssl x509 -outform der -in cacert.pem -out cacert.der

Install SSL Certificate

Add a mail account on IOS, and send the certificate to that account by email.
Click the certificate on IOS, and install by following the prompts.




After that, you can see it in Settings–>General–>Profiles.

Trust SSL Certificate

Goto Settings–>General–>About–>Certificate Trust Settings, turn the certificate on.

Configure HTTPS Proxy

For study purpose, you can install Surge and Shadowrocket free through www.i4.cn and www.25pp.com.
Here use the Shadowrocket for example.
